Celebration Rolling Ball Clock

This is Celebration: a tabletop, spring-driven, rolling ball clock with a compound balance pendulum and parallelogram grasshopper escapement. This is a nearly silent clockworks that releases a steel ball every five minutes, but on the hour, as the balls are returned below, it's a Celebration! As the minutes race tilts and spills its eleven extra balls into the serpentine race, it then falls back to hit the large bell with a "CLANG!" One ball from the minutes race enters the hour race, and then the remainder of the eleven minutes balls are let down into the collection area by a drop wheel that also dings a little bell for each ball dropped. Of course the bells are optional, and the dropping balls can be silenced with a felt pad...but then it would not be a celebration! (However, your partner might be less reluctant to allow it into the house. Ha)

See (and hear!) Celebration in action on the video player below, or click here: Celebration on YouTube

Here you can see the Celebration just a few seconds before 8:55. See the ball above about to enter the races? The individual minutes are shown on the frame as the ball progresses up toward the exit hole. On the far left of this picture you can also see the "Flapper" that gives even more movement as the hour balls smack into it before heading for the "U-Turn" race and into the collection area.

Here you can see both the Minute and Hour Serpentine races that direct the balls back down into the collection area. In back you can also see the constant force spring that drives the Celebration for about 40 hours on a wind.

The method that I created for constructing these races is extremely simple, and then each part fits easily onto the front frame.

This is the unique parallelogram, push-push grasshopper escapement. It is exceedingly easy to build, easy to adjust, very dependable, and almost totally silent, and best of all, it is absolutely full of grasshopper movement!

Below are pictures of Jeff Hecht's beautiful interpretation of the Celebration! Jeff has created an exceptionally spectacular clockworks. Notice, as you can peruse the pictures of his magnificent build, that his clock is showing 6:32. Jeff has also added a second "Flapper" onto the top race for even more movement in his clock. The details that Jeff has added to his build make all the difference!


Celebration Rolling Ball Clock, built by Jeff Hecht


Celebration built by Jeff Hecht, detail


Celebration Rolling Ball Clock, built by Jeff Hecht


Celebration Rolling Ball Clock, built by Jeff Hecht


Celebration Rolling Ball Clock, built by Jeff Hecht

Brad Smith's Celebration gathering an audience at the fair.  Waiting for one o'clock!

See other builders' interpretations of my Celebration Rolling Ball Clock design here: Celebration Flickr Pool

See other Celebration builders' YouTube videos here: Celebration Playlist on YouTube

Celebration! plans are available in TWO different formats. Please choose only one option:

The price of the paper plan delivered by mail is $50.00 plus shipping. If you would like to purchase Celebration paper plans by USPS mail, click here:


If you would like to purchase electronic plans in dxf format and receive them via email, you must:

1. Have a CAD program that can read dxf's.

2. Have a valid email address that can receive a 5 MB attachment. Add to your safe senders list so we don't end up in your spam filter.

If you prefer the dxf/email option, you will not receive a paper copy by regular mail. Plans purchased with the dxf option will be delivered to your inbox as an email attachment after payment is received, usually within 24 hours. The price of the dxf plan delivered via email is $42.00. To purchase dxf plans via email for Celebration, click below:
